ABPM 6100 Hardware Manual
DIR 80012720 Ver. E 13 / 28
3. Interface
This section describes how to connect the ABPM 6100 monitor to your PC and how to set
up patients for monitoring sessions.
To set up the ABPM 6100 for communication to your PC for the first time:
Windows XP Windows 7/ Windows 8
1. Right-click on My Computer. 1. Right-click on Computer.
2. Select Properties. 2. Select Properties.
3. Click the Hardware tab.
4. Click the Device Manager. 3. Click the Device Manager.
5. Double-click Ports (COM & LPT) 4. Double-click Ports (COM & LPT)
6. Plug the ABPM 6100 PC Interface Cable
into a USB port on your PC. Allow
Windows to install the driver.
5. Plug the ABPM 6100 PC Interface Cable into a
USB port on your PC. Allow Windows to install the
driver.
