ABPM 6100 Hardware Manual
DIR 80012720 Ver. E 12 / 28
At this point the unit will be ready to upload a BP Study. When the unit is turned on
subsequently, the unit will display the following:
-
Three quick audible beeps.
- The number of BP readings (if any) in memory along with a flashing printer symbol for 3
seconds.
- One long audible beep.
- Displays flashing time for 20 seconds (after 20 seconds the units turns itself off and
goes into Sleep Mode to conserve battery life)
The LCD Display
The LCD displays the following information depending upon the state that the unit is in:
-
The time is displayed whenever the unit is in Normal Mode and ready for an action.
- A sun symbol is displayed whenever the buzzer is on (usually during the day).
- A Crescent Moon symbol is displayed when the buzzer is off (usually during
programmed sleeping periods).
- A clock is displayed whenever the unit is in Study Mode.
- A battery symbol is displayed whenever the battery voltage is low and the batteries
need to be replaced.
- A printer symbol indicates that the unit contains readings in the memory.
