Head Configuration
VR Configuration
On an ICE head with VR compatibility, ICE Tool is used to enable and
configure the VR settings. Changes can be made to the VR data output
standards.
1. Right-click on the Vri component and select Open.
2. The Vri window opens. The following configuration settings can be
changed:
a) An identification number can be assigned to a VR head in a
multi-camera system. This number is then transmitted as part
of the VR data packet. Enter a number in the Camera Id field.
b) To output the VR data as serial comms, click to select SERIAL
from the Output Comms Type drop-down menu. Click to
select the required data rate in the Serial Settings field.
c) To output the VR data on Ethernet, click to select UDP from
the Output Comms Type drop-down menu. Enter the
connection details of the VR hardware in the Receiver
Address and Receiver Port fields.
d) If the VR data output is not synchronised with a genlock signal,
select the Allow Free Running check box.
