Vinten Radamec ICE Tool - Manual (Page 11)

9
General Device Configuration
Removing Devices
If an ICE device is no longer required to be connected to ICE Tool, or it
has been added in error:
1. Right-click on the host ID of the ICE device, then select Delete.
2. When the confirmation window appears, click Yes to delete the
ICE device from the system.
Opening Devices and Components
To open an ICE device for configuration:
1. Expand the System tree structure and then the required product
folder (example shown is FHR35)
2. Expand the host ID structure of the required ICE device (example
shown is 620-5B4). The individual components of the device are
displayed.
3. The active components of the ICE device are represented by
green icons
. Right-click on the required component and select
Open to enter the specific component configuration window.
Note
The delete function is also available on the product folder to
remove all ICE devices of the same type from the System
tree simultaneously.
