Vinten Radamec ICE Tool - Manual (Page 12)

10
General Device Configuration
Ethernet Configuration
The Ethernet settings of an ICE device are accessed and configured
using ICE Tool.
1. Open the required ICE device for configuration.
2. Right-click on the Hcm component of the device and select Open.
3. The Hcm window opens.The Network Configuration field
displays the current Ethernet settings.
4. To change the Ethernet configuration to a specific IP address:
a) If enabled, deselect Use DHCP in the Static Configuration
area.
b) Enter the required IP address and subnet mask in the
appropriate fields (example shown is for a standard VRC
control system setup).
c) Click Apply to save the new configuration.
Note
In the example shown Use DHCP is selected. This allows
the device to assign its own IP address on a DHCP network.
Note
Use the Default button to return the Ethernet configuration
to the factory settings.
