Page 9: Changing the position of a sliding shelf
9
GB
Layout advice
Your Transtherm wine cabinet has been designed to safely hold a maximum
number of bottles. We recommend that you observe the following advice
to optimize loading.
•
Distribute your bottles as uniformly as possible over the various cabinet
shelves, in order to spread the weight. Also ensure that none of the bottles
is touching the rear wall of the cabinet.
•
Spread the load over the entire cabinet rather than placing bottles all at
the top or all at the bottom.
•
Observe the loading instructions for the specific storage layout of your
cabinet and never stack bottles on a sliding shelf.
•
If you have sliding shelves, it is preferable to position them in the upper
section of your cabinet to facilitate daily access.
•
In the same way, place one or two bottles of each of your
different wines on the sliding shelves and keep spare bottles on
the storage shelves. You then simply replace bottles when they
are consumed.
•
When using your wine cabinet, never pull out more than one
sliding shelf at a time.
NB: Never modify the position of the stiffener in your wine
cabinet (see description page 5) without first consulting your
retailer and never handle this part when the cabinet is loaded.
Adding sliding shelves
When you purchase your cabinet, the sliding shelves are already adjusted to ideally suit the internal dimensions of your appliance. If you purchase a new
sliding shelf, you may have to carry out this adjustment. To do so, unscrew the screws 1 of the first right or left runner 2 (2 screws) then position the
runner at the desired width and tighten the screws. Repeat this process for the second runner (if necessary).
Wall
Guide
•
Completely unload the sliding shelf.
•
Then remove the sliding shelf by sliding it towards you whilst lifting the front section.
•
Remove the slide guides from the walls, marking off the right guide and the left guide.
•
Refit them (see diagram below).
Changing the position of a sliding shelf
Wall
Guide
Wall
Guide
A. Putting in place the back section of the
guide
B. Putting in place the front section of the
guide
Wall
Guide
Different types of storage
Universal storage shelf
Ref.: AXUHT
Universal sliding shelf
Ref.: ACUPHT
The layout of your cabinet can be modified
according to your requirements.
Refer to pages 16-19 to see storage
simulations.
Capacity: 77 bottles
Max weight: 100 kg
Capacity: 12 bottles
1
2
2
1
2
