Door reversibility
x3 x4 x3
C E
x3
D B G F H J A
x2
1
2
4
3
This allows you to change the direction in which the door opens. Follow
the instructions below (example for changing a right-hand door into a left-
5
Unscrew the door pin.
6
Carefully remove the cap using a thin blade and assemble the pin in its
place. Reposition the cap on the opposite side
9
Unscrew the handle.
10
Turn the door through 180°.
11
Screw the handle.
Warning: the door is very heavy. Take any necessary
precautions to ensure that you do not injure yourself or drop it.
12
Put the door back on its pin.
14
13
15
hand door):
1
Unscrew the three screws using a "T25" Torx wrench.
2
Remove the upper hinge.
3
Carefully remove the caps using a thin blade.
4
Remove the cabinet door by opening it slightly, then lifting it upwards.
13
Put in place the upper hinge.
14
Screw the hinge so that the door is completely parallel to the cabinet.
Check that the door seal adheres well to the cabinet (by closing the door),
to ensure that it is completely air-tight.
15
Put in place the caps.
7
Unscrew the four screws.
8
Fasten the door catch on the opposite side of the cabinet using the screws.
8
7
A
Upper hinge
B
Caps
C
Caps
D
Torx screw
E
Phillips screw
F
Door catch
G
Lower hinge
H
Door pin
J
Door pin cap
10 11
9
180°
4 - i
nstAllAting your Wine cABinet
NB : The handle of your wine cabinet is r
emovable. If you
wish to remove it, just unscre
w the 4 screws (see drawing 9)
and obturate the 2 holes at the top of the door with the 2
plastic caps you could find into the accessories
‘sack.
