Cabinet body
B
Setting and control panel
C
Lighting (2 LEDs)
D
Door catch
E
Sliding shelf
F
Cabinet stiffener (do not remove) – large model only
G
Storage shelf
H
Grill
I
Humidity cartridge
(1 temperature model only)
J
2 adjustable feet for levelling
K
Lower hinge (x2)
L
Product identification label
M
Thermodynamic pump aperture
N
Door (fitted with a removable handle and
a dual-action lock)
O
Upper hinge
P
Red service temperature compartment
(3 temperatures model)
Q
Chilled wine compartment
(3 temperatures model)
R
Cellar board (solid door only)
C
D
F
G
E
I
H
B
O
M
L
K
N
A
J
P
Q
R
1 - D
