User’s Manual TP-MS608/616
7
TYCON POWER SYSTEMS
RJ-45 Remote Control Port
TP-MS608/616 can remotely manage the PoE via the network. To manage
TP-MS608/616, you must to set the TP-MS608/616 TCP/IP parameter.
TP-MS608/616 allowed you to use a standard Web-browser such as Microsoft Internet
Explorer or Mozila, to set the TCP/IP parameter.
Before you use the web interface to set the PoE TCP/IP, verify that TP-MS608/616 is
properly installed on your network and PC on the network can access PoE via the
web-browser.
1. Verify that PC network interface card (NIC) is operational on the TCP/IP protocol.
2. Supply power to TP-MS608/616.
3. Use RJ45 cable, connect TP-MS608/616 direct to your PC.
4. Make sure the TP-MS608/616 default IP is 192.168.1.10.
5. Set your PC IP to 192.168.1.2 or other IP address which is located in the
192.168.1.x subnet.
6. Make sure the connector is OK (Ping 192.168.1.10 on the DOS mode).
7 Start the web-browser and type http://192.168.1.10 (or used PoE IP setting icon in
the PoE management software).
8. The login in screen will appear next.
