User’s Manual TP-MS608/616
5
TYCON POWER SYSTEMS
The Front Panel of the TP-MS608/616 consists of 8/16 x RJ-45 Ethernet ports (data),
8/16 x RJ-45 PoE ports (data + power), 8/16 x LED port indicators, one LED power
indicator and one RJ-45 remote control port(include one LED).
LED Indicators
The LED Indicators gives real-time information of systematic operation status. The
following table provides descriptions of LED status and their meaning.
LED Status Color Description
RJ45
On Green
A network device is
detected(10/100/1000 Mbps)
but no communication activity is
detected
Blinking Green
The Ethernet port is transmitting
to, or receiving package from
another device
Off -- No device is detected
Power
On Green Power feeding normally
On Red Power or fan alarm
Off -- Power off
Ports
On Green Power feeding
Blinking Orange Detecting
On Orange
The port has been shutdown
No power feeding
On Red
Alarm
No power feeding
Off --
Unknown device attached
No power feeding
Table 2-1. The Description of LED Indicators
