Tycon Power TPDIN-Monitor-WEB - Manual

TPDIN-Monitor-WEB
Web Based Monitor and
Control
▫ Remote Power Stations
▫ Backup Power Systems
▫ Solar Systems
▫ Wind Powered Systems
▫ Industrial Sense & Control
▫ Process Automation
Congratulations! on your purchase of the TPDIN-Monitor-WEB
PowerSens™ System Monitor. Please take a moment to review
this Qwik Install Guide before installation.
Recommended Tools and Supplies: Small Flat Blade Screwdriv-
er, 35mm x 7.5mm DIN Rail
Qwik Install
STEP 0: The TPDIN-Monitor-WEB can be used to monitor Qty 4 1V-
80V Voltages, 4 Currents ( Qty 2 +/- 10A and Qty 2 +20A) and two tem-
peratures (1 internal and 1 external). There are 4 10A relays that can be
used to control power to 4 devices. Two of those relays can be auto-
matically set based on a temperature or voltage value. Two can be op-
erated automatically based on a ping watchdog or time control.
STEP 1:
Install the TPDIN-Monitor-WEB to a suitable DIN rail mount.
STEP 2: Connect the voltages to be monitored to the V1—V4 voltage
ports. The green connector needs to be removed to be able to access
the wire terminal screws. The green connectors are numbered 1-7 and
should be re-installed back in their proper position. Voltages between 1
and 80volts DC can be monitored.
STEP 3: Connect the currents to be monitored to the I1-I4 current ports.
I1 and I2 can read currents from 0.1 to 20A. I3 and I4 can read positive
or negative currents to +/-10A. These can be used to measure current
flowing into and out of a battery to see if the battery is charging or dis-
charging. The green connectors may need to be removed to be able to
access the wire terminal screws. The green connectors are numbered
1-7 and should be re-installed back in their proper position.
