Technical specification – Tycon Power TP-MS608/616 User Manual
Page 31

User’s Manual
TP-MS608/616
31
TYCON POWER SYSTEMS
5. Technical Specification
PARAMETER
TP-MS608
TP-MS616
Data Ports
8
16
PoE Ports
8
16
Console Port
1× RJ45 console interface for management
Output power
Per port DC 55V@700mA
Power consumption
(maximum)
288W
576W
AC Input
100~240VAC,50/60Hz
DC Input
-42~-57VDC
DC Input Current require
> 6A @ 48V
> 12A @ 48V
Environment
Operating Temperature: 0
℃
~65
℃
Storage Temperature: -20
℃
~80
℃
Humidity: 10%~95%RH (non condense)
Dimensions
430mm(L) x 290mm(W) x 44mm(H), 19” Rack-Mount / 1U
Weight
3.6kg
4.9kg
