Page 32
– 28 –
DRWG.NO.
REV. PARTS NO.
PARTS NAME
Q'TY
REMARKS
RANK
Main Logic Board
JP1A
NPN
CHIP RESISTOR 0 OHM 1/16W
1
JP1B
NOT MOUNTED
JP2
NOT MOUNTED
LED1-2
NPN
LED CHIP LT1E40A*
2
LED3
NPN
LED CHIP LT1D40A*
1
R101
NPN
CHIP RESISTOR 1.5 KOHM 1/16W
1
R102
NPN
CHIP RESISTOR 10 K-OHM 1/16W
1
R103
NPN
CHIP RESISTOR 2.2 K-OHM 1/16W
1
R104
NPN
CHIP RESISTOR 22 K-OHM 1/16W
1
R105
NPN
CHIP RESISTOR 1 K-OHM 1/16W
1
R106
NPN
CHIP RESISTOR 470 OHM 1/16W
1
R107
NPN
CHIP RESISTOR 1 K-OHM 1/16W
1
R108
NPN
CHIP RESISTOR 470 OHM 1/16W
1
R109
NPN
CHIP RESISTOR 100 OHM 1/16W
1
R116-119
NPN
CHIP RESISTOR 10 K-OHM 1/16W
4
R120-121
NOT MOUNTED
R122-124
NPN
CHIP RESISTOR 10 K-OHM 1/16W
3
R125
NOT MOUNTED
R126-127
NPN
CHIP RESISTOR 10 K-OHM 1/16W
2
R128-130
NPN
CHIP RESISTOR 330 OHM 1/16W
3
R131-134
NOT MOUNTED
R135
NPN
CHIP RESISTOR 4.7 K-OHM 1/16W
1
R136-138
NPN
CHIP RESISTOR 10 K-OHM 1/16W
3
R139
NPN
CHIP RESISTOR 1 K-OHM 1/16W
1
R140-141
NPN
CHIP RESISTOR 10 K-OHM 1/16W
2
R142-145
NPN
CHIP RESISTOR 330 OHM 1/16W
4
R146
NPN
CHIP RESISTOR 220 OHM 1/16W
1
R147
NOT MOUNTED
R148-153
NPN
CHIP RESISTOR 330 OHM 1/16W
6
R154-158
NPN
CHIP RESISTOR 10 K-OHM 1/16W
5
R159-161
NPN
CHIP RESISTOR 100 K-OHM 1/16W
3
R163-164
NPN
CHIP RESISTOR 100 K-OHM 1/16W
2
R165
NPN
CHIP RESISTOR 470 OHM 1/10W
1
R166-170
NPN
CHIP RESISTOR 100 K-OHM 1/16W
5
R171-176
NOT MOUNTED
R177
NPN
CHIP RESISTOR 0 OHM 1/16W
1
R178
NPN
CHIP RESISTOR 100 OHM 1/16W
1
R179
NPN
CHIP RESISTOR 0 OHM 1/16W
1
R180
NPN
CHIP RESISTOR 100 OHM 1/16W
1
R181-185
NOT MOUNTED
R201-203
NPN
CHIP RESISTOR 10 K-OHM 1/16W
3
R204-206
NPN
CHIP RESISTOR 1 K-OHM 1/16W
3
R207
NPN
CHIP RESISTOR 330 OHM 1/16W
1
R208
NPN
CHIP RESISTOR 1 K-OHM 1/16W
1
R209
NPN
CHIP RESISTOR 15 K-OHM 1/16W
1
R210
NPN
CHIP RESISTOR 10 K-OHM 1/16W
1
R211-212
NPN
CHIP RESISTOR 10 K-OHM 1/10W
2
R213-216
NPN
CHIP RESISTOR 10 K-OHM 1/16W
4
R217
NPN
CHIP RESISTOR 330 OHM 1/16W
1
R218-220
NPN
CHIP RESISTOR 1 K-OHM 1/16W
3
R221-222
NPN
CHIP RESISTOR 330 OHM 1/16W
2
R223-226
NPN
CHIP RESISTOR 10 K-OHM 1/16W
4
R227-230
NPN
CHIP RESISTOR 100 OHM 1/16W
4
R231-234
NPN
CHIP RESISTOR 10 K-OHM 1/16W
4
R235
NPN
CHIP RESISTOR 15 K-OHM 1/16W
1
R236-237
NPN
CHIP RESISTOR 1.0 OHM 1W
2
