1-2. parts list – Rice Lake Star TSP-700 - Technical Manual User Manual

Page 19

background image

– 15 –

1

37450030 LOWER CASE UNIT TSP7

1

2

NPN

BOARD CHASSIS TSP7

1

3

30970040 THERMAL ROLL PAPER 80X35D

1

4

37457020 MAIN LOGIC BOARD UNIT TSP7

1

5

37457210 SUB-BOARD UNIT TSP7

1

6

38440000 TMP743-24

1

S

7

37451030 UPPER CASE UNIT TSP7

1

8

39607200 INTERFACE BOARD IFBD-HD03

1

OPTION:SERIAL 25 PIN

39607300 INTERFACE BOARD IFBD-HN03

1

OPTION:SERIAL 9 PIN

39607220 INTERFACE BOARD IFBD-HU03

1

OPTION:SERIAL USB

39607210 INTERFACE BOARD IFBD-HC03

1

OPTION:PARALLEL IF

9

30781180 ADAPTER SET PS60-24A JP

1

OPTION

30781190 ADAPTER SET PS60-24A US

1

OPTION

30781200 ADAPTER SET PS60-24A EU

1

OPTION

30781210 ADAPTER SET PS60-24A UK

1

OPTION

30781220 ADAPTER SET PS60-24A AS

1

OPTION

10

NPN

SWITCH COVER TSP8

1

11

01903101 SCREW TAT 3-6 CT-FL

9

12

00930609 SCREW TAT 3-6 CT

2

14

01903047 SCREW TAT 3-12 PT-FL

2

15

01903060 SCREW TAT 3-8 PT-FL

4

16

01903093 SCREW TR 3-25

1

17

NPN

FERRITE CORE K5BRC24X14X11

1

PARALLEL IF

18

04991204 FASTENER T18S

1

PARALLEL IF

3-1-2. Parts List

Printer Assembly

DRWG.NO.

REV. PARTS NO.

PARTS NAME

Q'TY

REMARKS

RANK
