7
RW 420 Vehicle Cradle Installation Guide
Required for Installation
• An electrical drill, 1/4”(6 mm) drill bit
• Common hand tools.
• #8-32 Screws or Bolts and appropriate mounting hardware
for securing the Vehicle Cradle
Note: Use of appropriate hardware used to secure the Vehicle Cradle to the
vehicle is the responsibility of the installer
Reference
• RW 420 User’s Guide
Contents of the Package
• The RW 420 Vehicle Cradle Assembly
• One of two power input cables: either (1) an unterminated
cable with an integrated fuse holder, or (2) a cable terminated
with a cigarette lighter adapter.
• Hardware for routing and securing the input power cable.
• This Guide
Installation
Introduction to Installation
The RW 420 Vehicle Cradle allows you to mount a RW 420 printer
into virtually any vehicle with an electrical system voltage range of
9 to 30 VDC. The installation kit provided with the Cradle includes
an input power cable which, when connected to the vehicle’s elec-
trical system, provides power to run the Printer and charge its bat-
tery.
The input power cable is wired to the vehicle’s battery power sys-
tem indirectly through a power take-off point. One version of the
Vehicle Cradle supplies an input power cable that can be plugged
into an automotive vehicle’s cigarette lighter.
CAUTION: Under no circumstances should this equipment be attached di-
rectly to the vehicle’s battery without a proper fuse.
Since each situation or equipment type may pose unique require-
ments, mounting hardware selection and mechanical installation
shall be the responsibility of the installer. Zebra recommends us-
ing self-locking (ESN) nuts, bolts, and/or lock washers for installing
the mount. The Cradle is secured with #8-32 mounting hardware
(4 places).
Note: Hardware used to secure the Vehicle Cradle to the vehicle is not
supplied in the installation kit.
Your tasks are to:
• Mechanically prepare and install the RW 420 Vehicle Cradle
