RoughDeck BDP Installation/Operation Manual
1.1
Model Designations
An identification tag is located on the frame next to the junction box tray. When ordering replacement parts, be
sure to include both the model and serial number of the scale.
Mild Steel
Mild steel versions come equipped with the following:
•
Treaded top plate
•
Aluminum NEMA 4 junction box
•
Alloy steel load cells
Stainless Steel
Stainless steel versions come equipped with the following:
•
Smooth top plate
•
Stainless steel NEMA 4X junction box
•
Stainless steel or stainless steel with welded seal (IP67) load cells
1.2
Operating Requirements
Electrical Grounding
For permanent installations where the scale is connected to a 115 VAC circuit, the indicator must be directly
connected to an earth ground with a ground interface cable of no more than 3W resistance throughout its length.
Load Cell Excitation
Rated Excitation:
10 VDC
Maximum Excitation:
15 VDC
Grade Level Requirements
The supporting surface for the four feet of the scale must be level within 1/4 inch of horizontal.
End Load Capacity
200% for 1K models
80% for 2.5K models
Scale to Indicator Cable Length
10 ft (3 m)
Approvals
NTEP CoC 03-060
