Chapter 4 – Menu System 41
IP ADDRESS Specifies the static IP Address of the interface in the standard octet format.
SUBNET MASK Specifies the static Subnet assigned to the interface, for example:
255.255.255.000.
GATEWAY Specifies the Gateway Address the interface will use, for example:
010.001.001.001.
SNMP TRAP
DESTINATION
Specifies the network IP Address where SNMP traps will be sent when SNMP service
is installed on your receiver. If zeroed, no traps are sent.
IP DISCOVERY Sets the address discovery method, where:
ENABLED The card broadcasts over the network to receive an addresses from the responsible
server at startup. Manual modifications to IP Address, Subnet Mask, or Gateway
Address are not allowed; and, if no server is found, the specified static value will be
used. (Default Setting)
;
A server assigned IP address takes precedence over any static IP
address stored in the interface.
DISABLED The stored static IP, Subnet Mask, and / or Gateway Address will be used.
SNMP Sets SNMP
ENABLED (Default Setting)
DISABLED
SET FACTORY
DEFAULTS Resets NIC Adapter parameters to the factory defaults values.
HOST SETTINGS Controls the communications with a host device, where:
;
The "ignore host" settings for ESC SEQUENCES, HEAT, SPEED,
TOF SENSING, SYMBOL SET, CNTRL-CODES, STX-V SW
SETTINGS, and MAX LENGTH will be unaffected when PL-Z Mode
is selected (see Input Mode for details ).
HOST TIMEOUT Sets the number of seconds (1 - 60) that an established communications port must
be idle before data can be received through an alternate port, where:
;
If the time-out period is exceeded before all data is received, the
data will be ignored.
10 Is the Default Setting.
CONTROL
CODES Allows changes to the prefix of the software commands interpreted by the printer,
where:
STANDARD
CODES Use these characters: Hex 01 = SOH command; Hex 02 = STX command; count-by
= ^; Hex 1B = ESC; Hex 0x0D = Carriage Return. (Default Setting)
ALTERNATE
CODES
Use these characters: Hex 5E = SOH command; Hex 7E = STX command; count-by
= @; Hex 1B = ESC; Hex 0x0D = Carriage Return.
ALTERNATE
CODES 2 Use these characters: Hex 5E = SOH command; Hex 7E = STX command; count-by
= @; Hex 1B = ESC; Hex 0x7C = Carriage Return.
CUSTOM
CODES Each DPL command (SOH, STX, CR, and count-by) may be selected by entering the
desired Hex code.
FEEDBACK
CHARACTERS
Allows the printer to return a Hex 1E (RS) after each label successfully prints, and a
Hex 1F (US) after each label batch successfully prints, where:
ENABLED Sends feedback characters to the host.
DISABLED Does not send feedback characters to the host. (Default Setting)
ESC
SEQUENCES
Allows data containing invalid ESC control code sequences to be processed, where:
ENABLED Processes commands normally. (Default Setting)
DISABLED Ignores ESC sequences are during processing (since some systems send a “banner”
to the printer). Bitmapped font downloads are disabled in this mode.
HEAT
COMMAND
Determines the way the DPL Heat command is handled, where:
ENABLED Processes commands normally. (Default Setting)
DISABLED Ignores DPL Heat commands; instead, the heat value is controlled via the menu
setting.
