38 Chapter 4 – Menu System
COLUMN
EMULATION
Allows the column dots per inch to be adjusted (153 - 203 dots), so that numbers
smaller than the printhead resolution reduce the printed output from right to left,
where:
XXX Dots
ROW EMULATION Allows the row dots per inch to be adjusted (103 - 303), so that numbers smaller
than the printhead resolution enlarge the height of the printed output and numbers
larger reduce it, where:
XXX Dots
SOP EMULATION Allows label positioning commands to function with backward compatibility when
printing label formats designed for legacy models, where:
DISABLED Produces the natural start of print position. (Default Setting)
110 (PRODPLUS) Emulates the Prodigy Plus® start of print position.
220 (ALLEGRO) Emulates the Allegro® start of print position.
250 (PRODIGY) Emulates the Prodigy™ start of print position.
;
When changing these values, the printer will automatically feed two labels to setup the new
print position.
BACK AFTER PRINT Determines the timing of the label's movement when a cutter, present sensor, peel
and present, or GPIO option is enabled, where:
ENABLED Allows fastest throughput; immediate label back-up occurs after the cut operation,
when the present sensor is cleared, or upon receipt of the GPIO start of print
signal.
DISABLED In order to prevent edge curling, label back-up is initiated only when the next label
is ready to print. (Default Setting)
BACKUP DELAY
(1/50s)
Instructs the printer to retract a presented label after a specified time elapses (0 –
255, in one-fiftieth of a second increments), where:
000 Retraction occurs when the next label is received and processed to print. (Default
Setting)
FONT EMULATION Allows font substitution for all internal fonts (see examples), where:
STANDARD
FONTS Prints using a standard (internal) font. (Default Setting)
CG TIMES Prints using the CG Times font.
USER ID S50 Prints using a downloaded font.
LABEL STORE Determines the command recall level used when retrieving stored label formats,
where:
STATE & FIELDS Recalls the printer state (i.e., heat, speed settings, etc.) and the label-formatting
commands for the stored label. (Default Setting)
FIELDS ONLY Recalls the label-formatting commands for the stored label.
MENU LANGUAGE Selects the menu and configuration label language. Only languages that are
resident will be displayed, where:
ENGLISH Enables English (Default Setting)
FRANCIAIS Enables French
ITALIANO Enables Italian
DEUTSCH Enables German
ESPANOL Enables Spanish
