CS1500, Users

Rev S, June, 2009

26

Parts List: 250 lb, 500 lb capacity

Item # QTY

Part #

Description

1

1

601008

jam nut

2

1

220063

4-pin MTA

3

1

603055

loadcell (250, 500 capacity CS1500)

4

1

601008

jam nut

5

1

500742

scale housing

6

1

601003

8-32 nut

7

2

500708

end plate

8

2

500707

battery tube

9

26

600008

6-32 screw

10

4

330030

battery spring

11

2

500706

battery cap plate

12

2

280074

cap plate back spring

13

2

500705

battery cap

14

2

602422

o-ring

15

2

600014

8-32 screw

17

1

603000

safety latch

18

1

500608

swivel

19

1

601055

.250 clevis pin

20

1

601056

cotter pin

21

1

602009

.25-28 shoulder bolt

22

1

500607

hook

23

1

000094

A/D board

24

18

601207

.031 nylon washer

25

2

500703

board mounting strap

26

4

600012

8-32 screw

27

6

601002

6-32 nut

28

4

601311

8-32 vibration mount

29

4

601315

6-32 standoff

30

2

601301

6-32 f/f standoff

31

2

601208

.062 nylon washer

32

1

000092

LED display board

33

1

500737

display plate

34

1

250001,
250087

keypad assembly

35

1

500730

bezel frame

36

2

600163

6-32 screw

37

2

601314

.25 spacer

38

1

502859

heatsink plate

39

2

601313

.19 spacer

40

1

220063

4-pin MTA

41

1

600020

.25-20 torx screw long

42

1

600020

.25-20 torx screw long

43

1

500709

retaining ring

44

1

500710

retaining ring gasket

45

1

500614

top lifting eye assembly
