26
9.0 Optional Equipment
The following option is available for the IQ6200 series:
• Rechargeable battery pack
The following options are available for the IQ6500 series:
• Remote input channel
• Bi-directional RS-232 communications port (required for all of the accessories listed below)
• Bar code input using a laser or pen scanner
• Setpoint TTL outputs for process control
• Ticket printer
• Tape printer
• Thermal label printers
To obtain more information than is offered in this section or to retrofit your scale, please consult your Rice
Lake Weighing Systems distributor.
9.1 Bar Code Input
Bar code input is available using either a laser scanner or a wand (or pen) scanner. The laser scanner allows
non-contact, instantaneous, accurate input of unit weight, tare weight, and ID code.
Scanners connect to the circular DIN connector marked “bar code” in the rear of the scale. The pen reader is
an economical way to use the accuracy and speed of bar code data input when contact scanning is available.
Be sure to verify the correct settings on SPEC17, bits 1 and 0.
9.2 RS-232 Communications Port
The bi-directional RS-232 port can be used to communicate with a computer for database handling. This is
the 25-pin rectangular connector located in the rear of the scale. The following sections describe RS-232
specifications, configurations, and installation.
Notes:
Custom software may be available to fit your needs. See your RLWS distributor for information.
9.2.1 Connector Type
The following connector pins are found on the RS-232 25-pin D-type and 8-pin DIN connectors:
25-pin Connector 8-pin RS-232 Connector
1 - F. gnd. Frame ground 1 -
2 - TXD Transmit data 2 - Gnd Ground
3 - RXD Receive data 3 -
4 - RTS Request to send 4 - RXD Receive data
5 - CTS Clear to send 5 - TXD Transmit data
6 - DSR Data set ready 6 - CTS Clear to send
7 - S. gnd. Signal ground 7 - RTS Request to send
8 - RLSD Receive line signal detector 8 -
20 - DTR Data terminal ready
