QOMO QD700 User Manual
Page 27
RGB Output Pixels
780,000
22 x optical zoom, 10 x digital zoom
Lens
F=1.6~3.7mm / f=3.9~85.8 mm
Focus/Iris Auto/manual
selectable
White balance
Auto
Image split
Yes
Negative/positive
conversion
Yes
Black/white and color
selection
Yes
Image Freeze
Yes
Mirror Yes
Arm light: 1.5 W LED lamps x 2
Lights
Back light: 4 W LED lamps
C-Video: RCA jack 1
S-Video: 4 pin mini Din 1
Audio: Mini jack 2
MIC: Mini jack 1
PC Audio: Mini jack 2
Input connectors
RGB: DB15FLC 2
RGB DB15FLC 2
C-Video: RCA jack 1
S-Video: 4 pin mini Din 1
Output connectors
Audio: Mini jack 1
Operating system
Windows 2000/XP
USB connector
30 frames/sec
RS-232 connector
9-pin, D-Sub, male/6-pin PS/2
USB port
USB 2.0
Power requirements
12V/4A external AC adapter
Folded: 20.0
″ x 16.1″ x 4.7″
Setup: 20.0
″ x 20.9″ x 22.4″
Dimension (W x D x H)
Packing: 25.6
″ x 21.3″ x 9.1″
Weight
N.W: 5.5Kg (12.1lbs)
27
