KEY # KIT/ PART DESCRIPTION PART NO. SPARE PARTS DESCRIPTION
SPARE PARTS LIST
1 Servo saver bottom A-1620 XXX Steering/Servo Mount Assembly (Molded)
2 Servo saver post A-1610 Steering Hardware Set
3 Servo saver top A-1620 XXX Steering/Servo Mount Assembly (Molded)
4 Servo saver spring A-1610 Steering Hardware Set
5 Servo saver spring cap A-1620 XXX Steering/Servo Mount Assembly (Molded)
6 6-40 locknut A-1610 Steering Hardware Set
7 4-40 mini locknut A-6306 4-40 Aluminum Mini Nuts (10)
8 Steering idler arm A-1620 XXX Steering/Servo Mount Assembly (Molded)
9 Ball stud washer A-6215 #4 Narrow Washers (10)
10 1/4" ball stud A-6006 Ball Studs w/Rod Ends 4-40 x 1/4" (4)
11 3/16" ball stud A-6001 Ball Studs w/Rod Ends 4-40 x 3/16" (4)
12 Steering drag link A-1620 XXX Steering/Servo Mount Assembly (Molded)
13 3/32" x 3/16" plastic bushing A-1620 XXX Steering/Servo Mount Assembly (Molded)
14 Front kickplate A-4122 XXX Front Kickplate, Bulkhead, and Steering Brace
15 Steering brace A-4122 XXX Front Kickplate, Bulkhead, and Steering Brace
16 3/32" x .930" hinge pin A-1146 Front Outer & Kingpins 3/32" (XX, ‘CR’, XXX)
17 4-40 x 3/8" cap-head screws A-6206 4-40 x 3/8" Cap-Head screws (10)
18 Threaded insert A-4224 Threaded Chassis Inserts - Short and Long
19 Main chassis A-4107 XXX-T Main Chassis and Brace
20 Front bulkhead A-4122 XXX Front Kickplate, Bulkhead, and Steering Brace
21 4-40 x 3/8" button-head screw A-6229 4-40 x 3/8" Button-Head Screws (10)
22 4-40 x 1/4" flat-head screw A-6213 4-40 x 1/4" Flat-Head Screws (10)
23 4-40 x 7/8" cap-head screws A-6216 4-40 x 7/8" Cap-Head Screws (10)
24 Front shock tower A-1109 XXX-T Front Shock Tower
25 4-40 nut A-6300 4-40 Hex Nuts (10)
26 3/8" ball stud A-6000 Ball Studs w/Rod Ends 4-40 x 3/8" (4)
27 3/16" x 3/8" sealed bearing A-6903 3/16" x 3/8" Teflon™-Sealed Bearings (2)
28 Left spindle A-4125 XXX-T Front Spindles/Carriers, and Rear Hubs
29 Right spindle A-4125 XXX-T Front Spindles/Carriers, and Rear Hubs
30 Front axle A-1022 Front Axles for XX-T Wheels (GTX, NXT, XXX-T)
32 5-40 setscrew A-6228 5-40 x 1/8" Hardened Set Screws
33 Left spindle carrier A-4125 XXX-T Front Spindles/Carriers, and Rear Hubs
34 Right spindle carrier A-4125 XXX-T Front Spindles/Carriers, and Rear Hubs
35 1/8" x .960" hinge pin A-1150 Front Outer Hinge Pin (XXX-T)
36 Front spindle spacer A-5050 Shock Spacer Set
38 Front suspension arm A-1116 XXX-T Front Suspension Arms
39 Front pivot block A-4126 XXX Front and Rear Pivot Block Set
40 1/8" x 1.42" hinge pin A-2007 Hinge Pin 1.42" (XXT, XXX)
41 1/8" E-clip A-6100 1/8" E-Clips
42 Front hinge pin brace A-4136 XXX Front and Rear Inner Pin Brace Set
43 Front bumper A-4118 XXX Front Bumper, Motor Guard, and Body Mounts
44 4-40 x 1/2" flat-head screws A-6220 4-40 x 1/2" Flat-Head Screws (10)
45 Plastic rod end A-6005 H.D. 30 o Plastic Rod Ends (16)
46 2-1/4" turnbuckle A-6068 Adjustable Threaded L/R Rod Set w/ends (2.25")
47 Foam thing A-6003 Foam Things (Linkage Rings) (24)
48 1/8" x 1/4" washer A-6350 #4 and 1/8" Hardened Washers
49 Rear pivot block A-4126 XXX Front and Rear Pivot Block Set
50 Rear suspension arm A-2141 Rear Suspension Arms (XXT ‘CR’, XXX-T)
51 Shock mount bracket A-2141 Rear Suspension Arms (XXT ‘CR’, XXX-T)
52 Inner rear hinge pin A-2166 XXX Inner Rear Hinge Pins
53 Rear pivot plate A-2108 XXX Rear Pivot Plate
54 4-40 x 3/8" flat-head screw A-6210 4-40 x 3/8" Flat-Head Screws (10)
55 Rear shock tower A-2103 XXX-T Rear Shock Tower
56 Front body mount A-4118 XXX Front Bumper, Motor Guard, and Body Mounts
57 4-40 x 1/2" cap-head screw A-6204 4-40 x 1/2" Cap-Head Screws (10)
58 #4 washer A-6350 #4 and 1/8" Hardened Washers
