MARS User´s Guide
If the resistor R2 is changed to R6 the PS_ON signal is always active. I. e. that all voltages
Note:
generated by the SBS MARS are available at the output continuous.
11.3 Control LEDs
The SBS MARS offers the possibility to show the user the state of all output voltages by LEDs.
Pressing the “LED on” button S2 will activate the LEDs when the output voltages are switched on:
h D11 for 12V
h D10 for 5V
h D9 for 5V Standby
The LEDs are only active when the S2 button is pressed. To save power while running the system is
not switching on the LEDs continuously.
Activating and Deactivating of the SBS MARS
23
