Kontron MARS Smart Battery Kit User Manual
Page 21
MARS User´s Guide
8.2.2 How to bypass the 12V path of the dual buck converter
h
Connect +V12_OUT to +V12_out_BB Æ alter Power Jumper from R88 to R87
h
Populate R89 to connect the input voltage to the output dual buck converter
h
Populate R160 and remove R59 (both bottom side) to deactivate the 12V path of the
dual buck converter. The circuit of the dual buck converter could be omitted in this
case.
Dual Buck Converter
20
