MARS User´s Guide
3. Specifications
3.1 System components
h Smart Battery System Manager and Charger
• LTC 1760: Dual Smart Battery System Manager
h Buck-boost converter (at input and output each)
• LTC 3760
h Dual buck converter at output side
• LTC 3727
h CPLD
• Xilinx XC9536XL
3.2 Mechanical Specification
3.2.1 Size
h 185.0 mm x 160.0 mm (7.28” x 6.3”)
h Hight: 24 mm TBD
3.3 Elektrical Specification
3.3.1 Input voltage
h 5V DC to 28 V DC
3.3.2 Input power
h TBD
3.3.3 Smart Batteries
h NiMH and NiCd up to 10S1P
eg. 9S1P (10.8V), 10S1P (12V)
h LiIon and LiPo up to 4S3P:
eg. 2S2P (7.2V), 3S3P (10.8V), 4S3P (14.4V)
Specifications
10
