Introduction
This manual describes the KTGM45/mITX, KTGM45/Flex and KTGM45/ATXE boards made by KONTRON
Technology A/S. The boards will also be denoted KTGM45 family if no differentiation is required.
The KTGM45 boards supports the Intel® Core™ 2 Extreme Mobile Processor (Penryn), the Intel® Core™2
Quad Mobile processor (Penryn) Q9100, the Intel® Core™2 Duo Mobile processor (Penryn) and Intel®
Celeron® (Meron). At least one type Intel® Core™2 Duo processor (Penryn) has successfully been tested.
KTGM45 variants
Format PCI PCIe
x1
Mini-
PCIe ETH
Fire-
wire
CF CDROM
audio
HP
RTC
KTGM45/mITX Plus
mITX
1
-
1
3
2
1
-
1
KTGM45/mITX Plus wo CF
mITX
1
-
1
3
2
-
-
1
KTGM45/mITX Std
mITX
1
-
1
3
2
-
-
-
KTGM45/mITX Basic
mITX
1
-
1
1
-
-
-
-
KTGM45/Flex
Flex
2
1
-
3
2
-
1
-
KTGM45/ATXE
ATX
5
1
-
3
2
-
1
note1
Note1: removed from later version.
Use of this Users Guide implies a basic knowledge of PC-AT hard- and software. This manual is focused on
describing the KTGM45 Board’s special features and is not intended to be a standard PC-AT textbook.
New users are recommended to study the short installation procedure stated in the following chapter before
switching-on the power.
All configuration and setup of the CPU board is either done automatically or manually by the user via the
CMOS setup menus. Only exception is the Clear CMOS jumper (J13).
