KTGM45 Users Guide
KTD-N0793-O Page 36
3.6.3 PCI-Express x1 Connector (PCIe x16)
The KTGM45/Flex and KTGM45/ATXE supports one PCIe x1 in a x16 socket.
Note Type Signal PIN Signal Type Note
+12V B1 A1 NC
+12V B2 A2 +12V
+12V B3 A3 +12V
GND B4 A4 GND
SMB_CLK B5 A5 NC
SMB_DATA B6 A6 NC
GND B7 A7 NC
+3V3 B8 A8 NC
NC B9 A9 +3V3
SB3V3 B10 A10 +3V3
WAKE# B11 A11 RST#
NC B12 A12 GND
GND B13 A13 PCIE_x4 CLK
PCIE_TXP4 B14 A14 PCIE_x4 CLK#
PCIE_TXN4 B15 A15 GND
GND B16 A16 PCIE_RXP4
NC B17 A17 PCIE_RXN4
GND B18 A18 GND
NC B19 A19 NC
NC B20 A20 GND
GND B21 A21 NC
GND B22 A22 NC
NC B23 A23 GND
NC B24 A24 GND
GND B25 A25 NC
GND B26 A26 NC
NC B27 A27 GND
NC B28 A28 GND
GND B29 A29 NC
NC B30 A30 NC
NC B31 A31 GND
GND B32 A32 NC
NC B33 A33 NC
NC B34 A34 GND
GND B35 A35 NC
GND B36 A36 NC
NC B37 A37 GND
NC B38 A38 GND
GND B39 A39 NC
GND B40 A40 NC
NC B41 A41 GND
NC B42 A42 GND
GND B43 A43 NC
GND B44 A44 NC
NC B45 A45 GND
NC B46 A46 GND
GND B47 A47 NC
NC B48 A48 NC
GND B49 A49 GND
NC B50 A50 NC
NC B51 A51 GND
GND B52 A52 NC
GND B53 A53 NC
NC B54 A54 GND
NC B55 A55 GND
GND B56 A56 NC
GND B57 A57 NC
NC B58 A58 GND
NC B59 A59 GND
