KTGM45 Users Guide
KTD-N0793-O Page 59
5 System Resources
5.1 Memory Map
Address (hex) Size Description
00000000 0009FFFF 655360 System board
000A0000 000BFFFF 131072 PCI-bus
000A0000 000BFFFF 131072 Mobile Intel(R) 4 Series Express Chipset Family
000C0000 000CFFFF 65536 System board
000D0000 000DFFFF 65536 PCI-bus
000E0000 000FFFFF 131072 System board
00100000 3DBFFFFF 1034944512 System board
3DC00000 DFFFFFFF 2722103296 PCI-bus
D0000000 DFFFFFFF 268435456 Mobile Intel(R) 4 Series Express Chipset Family
E0000000 EFFFFFFF 268435456 Motherboard resources
F0000000 FED8FFFF 249102336 PCI-bus
FE000000 FE3FFFFF 4194304 Mobile Intel(R) 4 Series Express Chipset Family
FE600000 FE6FFFFF 1048576 Mobile Intel(R) 4 Series Express Chipset Family
FE7C0000 FE7DFFFF 131072 Intel(R) 82567LM Gigabit Network Connection
FE7F4000 FE7F7FFF 16384 Microsoft UAA-bus driver for High Definition Audio
FE7FA000 FE7FAFFF 131072 Intel(R) 82567LM Gigabit Network Connection
FE7FB000 FE7FB00F 16 PCI controller for simple communication
FE7FB400 FE7FB7FF 1024 Intel(R) ICH9 Family USB2 Enhanced Host Controller - 293C
FEAFB800 FEAFBBFF 1024 Intel(R) ICH9 Family USB2 Enhanced Host Controller - 293A
FE7FBC00 FE7FBCFF 256 Intel(R) ICH9 Family SMBus Controller - 2930
FE800000 FE8FFFFF 1048576 Intel(R) ICH9 Family PCI Express Root Port 2 - 2942
FE8FF000 FE8FFFFF 4096 OHCI Compliant IEEE 1394-Værtscontroller
FE900000 FE9FFFFF 1048576 Intel(R) ICH9 Family PCI Express Root Port 3 - 2944
FE9DC000 FE9DFFFF 16384 Intel(R) 82574L Gigabit Network Connection #2
FE9E0000 FE9FFFFF 131072 Intel(R) 82574L Gigabit Network Connection #2
FEA00000 FEAFFFFF 1048576 Intel(R) ICH9 Family PCI Express Root Port 4 - 2946
FEAE0000 FEAEFFFF 65536 PCI Standart PCI to PCI-Brigde
FEB00000 FEBFFFFF 1048576 Intel(R) ICH9 Family PCI Express Root Port 5 – 2948
FEBDC000 FEBDFFFF 16384 Intel(R) 82574L Gigabit Network Connection
FEBE0000 FEBFFFFF 131072 Intel(R) 82574L Gigabit Network Connection
FEC00000 FEC00FFF 4096 Motherboard resources
FED00000 FED003FF 1024 High Precision timer
FED10000 FED19FFF 40960 Motherboard resources
FED1C000 FED1FFFF 16384 Motherboard resources
FED20000 FED3FFFF 131072 Motherboard resources
FED40000 FED8FFFF 327680 Motherboard resources
FED90000 FFFFFFFF 19333120 System Board
FEE00000 FEE00FFF 4096 Motherboard resources
FFB00000 FFBFFFFF 1048576 Intel(R) 82802 Firmware-hub unit
FFC00000 FFEFFFFF 3145728 Motherboard resources
FFF00000 FFFFFFFF 1048576 Intel(R) 82802 Firmware-hub unit
System Resources
