KTGM45 Users Guide
KTD-N0793-O Page 33
3.6 PCI-Express connectors
The KTGM45/mITX supports one (x16) (16-lane) PCI Express port and one miniPCI Express port.
KTGM45/Flex and KTGM45/ATXE supports one PCIe x16 port and one PCIe x1 port (in a x16 connector).
The 16-lane (x16) PCI Express (PCIe 2.0) port can be used for external PCI Express graphics card. It is
located nearest the CPU. Maximum theoretical bandwidth using 16 lanes is 16 GB/s.
The PCI Express (x16) interface is multiplexed with the SDVO ports and TMDS ports.
The miniPCIe (PCIe 1.1) (KTGM45/mITX only) is located on the backside of the board.
Supports PCI Express GEN1 frequency of 1.25 GHz (supports 2.5 Gbit/s in each direction, 500 MB/s totally).
The 1-lane (x1) PCI Express (PCIe 1.1) port (KTGM45/Flex and KTGM45/ATXE only) is mechanically a x16
port and electrically a x1 port. It is located farthest away from CPU. Supports PCI Express GEN1 frequency
of 1.25 GHz (supports 2.5 Gbit/s in each direction, 500 MB/s totally).
3.6.1 PCI-Express x16/SDVO Connector (PCIe x16/SDVO)
Note Type Signal PIN Signal Type Note
+12V B1 A1 NC
+12V B2 A2 +12V
+12V B3 A3 +12V
GND B4 A4 GND
SMB_CLK B5 A5 NC
SMB_DATA B6 A6 NC
GND B7 A7 NC
+3V3 B8 A8 NC
NC B9 A9 +3V3
SB3V3 B10 A10 +3V3
WAKE# B11 A11 RST#
NC B12 A12 GND
GND B13 A13 PCIE_x16 CLK
PEG_TXP[15]/SDVOB_RED B14 A14 PCIE_x16 CLK#
PEG_TXN[15]/SDVOB_RED# B15 A15 GND
GND B16 A16 PEG_RXP[15]/SDVO_TVCLKIN
SDVO_CTRLCLK B17 A17 PEG_RXN[15] / SDVO_TVCLKIN#
GND B18 A18 GND
PEG_TXP[14]/SDVOB_GREEN B19 A19 NC
PEG_TXN[14]/SDVOB_GREEN# B20 A20 GND
GND B21 A21 PEG_RXP[14]/SDVOB_INT
GND B22 A22 PEG_RXN[14]/SDVOB_INT#
PEG_TXP[13]/SDVOB_BLUE B23 A23 GND
PEG_TXN[13]/SDVOB_BLUE# B24 A24 GND
GND B25 A25 PEG_RXP[13]/SDVO_FLDSTALL
GND B26 A26 PEG_RXN[13]/SDVO_FLDSTALL#
PEG_TXP[12]/SDVOB_CLKP B27 A27 GND
PEG_TXN[12]/SDVOB_CLKN B28 A28 GND
GND B29 A29 PEG_RXP[12]
NC B30 A30 PEG_RXN[12]
SDVO_CTRLDATA B31 A31 GND
GND B32 A32 NC
PEG_TXP[11]/SDVOC_RED B33 A33 NC
PEG_TXN[11]/SDVOC_RED# B34 A34 GND
GND B35 A35 PEG_RXP[11]
