KTGM45 Users Guide
KTD-N0793-O Page 68
7.3.2 Advanced settings – IDE Configuration
BIOS SETUP UTILITY
Advanced
IDE Configuration Options
Disabled
Compatible
Enhanced
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
Mirrored IDER Configuration [Disabled]
SATA#1 Configuration [Compatible]
Configure SATA#1 as [IDE]
SATA#2 Configuration [Enhanced]
► Primary IDE Master : [Hard Disk]
► Secondary IDE Master : [Not Detected]
► Third IDE Master : [Not Detected]
► Fourth IDE Master : [Not Detected]
► Fifth IDE Master : [Not Detected]
► Fifth IDE Slave : [Not Detected]
Hot Plug [Disabled]
► AHCI Configuration
Hard Disk Write Protect [Disabled]
IDE Detect Time Out (Sec) [35]
TA(PI) 80Pin Cable Detection [Host & Device]
JMicron 36x ATA Controller [Enabled]
v02.67+ (C)Copyright 1985-2009, American Megatrends, Inc.
Feature Options Description
SATA#1 Configuration Disabled
Compatible
Enhanced
Disabled
Compatible
Enhanced
Configure SATA#1 as IDE
RAID
AHCI
IDE
RAID
AHCI
SATA#2 Configuration Disabled
Enhanced
Disabled
Enhanced
Note: When RAID shall be used in XP then use “Floppy_F6” driver (load RAID driver via Floppy Disk). The
RAID driver must be installed even if the OS shall be executed from a HDD not included in the RAID. When
XP Installation CD is started then after approx. ½ minute it will for a few seconds ask you to press for
special driver selection (do that). System will continue loading files but after a minute or so it will ask you to
press the -key. Now load the Floppy Disk and press the key. Select the ”Intel(R) ICH9M-E/M SATA
AHCI Controller". System will ask you for more special drivers, but just skip that by pressing .
