The uEFI Shell CP3003-SA/CP3003-V uEFI BIOS
Page 46 ID 1053-4014, Rev. 2.0
D R A F T — F O R I N T E R N A L U S E O N L Y
OPTIONS:
(continued)
Sata0Speed Indicates maximum speed supported by SATA port 0
(SATA cable connector J3 on the CP3003-SA/
CP3003-V main board)
Available parameters for SATA0Speed and
SATA1Speed:
noLimit,
gen1 (SATA 1.5 Gb/s),
gen2 (SATA 3.0 Gb/s),
gen3 (SATA 6.0 Gb/s)
Sata1Speed Indicates maximum speed supported by SATA port 1
(SATA connector J6 on the CP3003-HDD module)
For available parameters, refer to SATA0Speed.
Sata2Speed Indicates maximum speed supported by SATA port 2
(SATA connector J6 on the CP-RIO3-04 module)
Available parameters for SATA2Speed to
SATA5Speed:
noLimit,
gen1 (SATA 1.5 Gb/s),
gen2 (SATA 3.0 Gb/s)
Sata3Speed Indicates maximum speed supported by SATA port 3
(SATA connector J5 on the CP-RIO3-04 module)
For available parameters, refer to SATA2Speed.
Sata4Speed Indicates maximum speed supported by SATA port 4
(CFast connector J3 on the 8 HP CP3003-SA/
CP3003-V with CP3003-HDD module / High-speed I/
O extension connector J4 for 12 HP CP3003-SA/
CP3003-V expansion)
For available parameters, refer to SATA2Speed.
Sata5Speed Indicates maximum speed supported by SATA port 5
(SATA connector J12 on the CP3003-SA/CP3003-V
main board for connection to the SATA Flash module)
For available parameters, refer to SATA2Speed.
Sata2Hotplug: Enable hotplug for SATA port 2
(SATA connector J6 on the CP-RIO3-04 module)
Sata3Hotplug: Enable hotplug for SATA port 3
(SATA connector J5 on the CP-RIO3-04 module)
kboardconfig (continued)
