CP3003-SA/CP3003-V uEFI BIOS Main Setup
ID 1053-4014, Rev. 2.0 Page 21
D R A F T — F O R I N T E R N A L U S E O N L Y
2.7.3.2.1 Out-of-Band Mgmt Port
This function is used to select the serial port intended for use with Out-of-Band Management.
Note: This function is available only when the respective serial port is enabled.
Default setting: COM0
2.7.3.2.2 Terminal Type
Default setting: VT-UTF8
2.7.3.2.3 Bits per second
Default setting: 115200
2.7.3.2.4 Flow Control
Default setting: None
2.7.3.2.5 Data Bits
This is a display-only function providing information about the frame width for the Out-of-Band
Management.
SETTING DESCRIPTION
COM0 Use this setting to specify that the serial port 0 is to be used with Out-of-Band Management
COM1 Use this setting to specify that the serial port 1 is to be used with Out-of-Band Management
SETTING DESCRIPTION
VT100 Use one of these settings to select the terminal type to be emulated.
VT100+
VT-UTF8
ANSI
SETTING DESCRIPTION
9600 Use one of these settings to select the baud rate of the serial port.
19200
57600
115200
SETTING DESCRIPTION
None Use one of these settings to specify the type of flow control to be used for this serial port.
Hardware RTS/CTS
Software Xon/Xoff
