CP3003-SA/CP3003-V uEFI BIOS Main Setup
ID 1053-4014, Rev. 2.0 Page 17
D R A F T — F O R I N T E R N A L U S E O N L Y
2.7.2 COM1
The COM1 port (serial port 1) corresponds to the COMB port (RS-232) and is available on the
rear I/O.
2.7.2.1 Console Redirection
Default setting: Disabled
2.7.2.2 Console Redirection Settings
This screen provides information about functions for specifying the Console Redirection con-
figuration settings for the serial port 0 (COM0) and serial port 1 (COM1). Each serial port can
be independently configured.
SETTING DESCRIPTION
Disabled Use this setting to disable console redirection for COMB (RS-232).
Enabled Use this setting to enable console redirection for COMB (RS-232).
A p t i o S e t u p U t i l i t y - C o p y r i g h t ( C ) 2 0 11 A m e r i c a n M e g a t r e n d s , I n c .
M a i n B o o t S e c u r i t y S a v e & E x i t
COM0
Console Redirection Settings
Terminal Type [ANSI]
Bits per second [115200]
Data Bits [8]
Parity [None]
Stop Bits [1]
Flow Control [None]
VT-UTF8 Combo Key Support [Enabled]
Recorder Mode [Disabled]
Resolution 100x31 [Enabled]
Legacy OS Redirection Resolution [80x24]

: Select Screen

: Select Item
Enter: Select
+/-:
Change Opt.
F1: General Help
F2: Previous Values
F3 Optimized Defaults
F4: Save & Exit
ESC: Exit
Ve r s i o n 2 . 1 4 . 1 2 1 9 . C o p y r i g h t ( C ) 2 0 11 A m e r i c a n M e g a t r e n d s , I n c .
