6.0 H-491269 Probe Stand
The ETS-Lindgren Probe Stand is
designed for EMC testing in anechoic
chambers and shielded enclosures. The
probe stand provides stable placement for
up to two probes.
P ROBE S TAND D IMENSIONS
Base Plate and
Tube Height:
2438 mm
96 in
Tube Height: 2248 mm
88.50 in
Base Width: 406 mm
16 in
Tube Width: 51 mm
2 in
H-491269 Probe Stand | 71
Archived 6/29/10
Use only the content for
HI-4422 in this manual.
Disregard content for
all other probe models;
see ETS-Lindgren
website for other
probe content.
