Fiber Optic Cable Connector: Standard FSMA
Battery: Rechargeable Nickel-Metal Hydride
(NiMH)
Battery Life: Up to 8 hours
Battery Charger: • 100–240 VAC universal input
• 2-hour charge from full depletion
Probe Mount: 1/4–20 UNC tapped hole (internal thread)
Dimensions:
Housing: 32 mm x 32 mm x 32 mm
1.26 in x 1.26 in x 1.26 in
Probe Shields: 43 mm (1.69 in)
Weight: 80 g (2.82 oz)
HI-6022 O PERATION
The HI-6022 can be used with the HI-6100 Field Monitor or the FM5004 Field
Monitor. It can also be connected to a personal computer using an optional
HI-4413P Fiber Optic Modem or HI-4413USB Fiber Optic to USB Converter and
ProbeView II™ software.
The HI-6022 is a true 3-axis probe. When requested, X, Y, Z, and total field data
can be reported.
For a list and description of communication and information transfer protocols,
including command structure and probe commands, see Appendix E: Operating
Protocols on page 105.
Battery-Operated Field Probes: HI-6022 Field Probe | 43
Archived 6/29/10
Use only the content for
HI-4422 in this manual.
Disregard content for
all other probe models;
see ETS-Lindgren
website for other
probe content.
