HI-6100 Field Monitor Configuration
The following diagram illustrates the ETS-Lindgren probes that may be used with
the HI-6100 Field Monitor. In the diagram, the FM in HI-6153FM, for example,
refers to Field Monitor Kit. As a kit, the probe includes an interface card.
18 |
Typical Configurations
Archived 6/29/10
Use only the content for
HI-4422 in this manual.
Disregard content for
all other probe models;
see ETS-Lindgren
website for other
probe content.
