HI-6122 A DDITIONAL M AINTENANCE
Maintenance of the HI-6122 is limited to external components such as cables,
connectors, and probe shields. For information on fiber optic cable and connector
maintenance, see Laser Probes and Maintenance of Fiber Optics on page 24. To
replace the probe shields, see Probe Shield Care and Replacement on page 79.
Any maintenance or calibration task requires probe disassembly,
which may void your warranty. Only ETS-Lindgren service personnel
should perform these tasks. To avoid problems with your warranty,
contact ETS-Lindgren Customer Service before performing any
maintenance.
For complete information on maintenance and calibration, see Maintenance on
page 23.
HI-6122 A DDITIONAL P ARTS
Use the following table to order replacement or optional parts for the HI-6122.
Part Description Part Number
Probe shield replacement Kit
includes:
• Three probe shields (cones)
• One each X, Y, and Z label
• Six screws
112955
Cable Assembly, Fiber, FC-FC,
ST-ST
H-491263-xx
(xx=length in meters)
FC to FC Inline Connector H-23861521000
ST to ST Inline Connector 708027
Carrying Case H-491291
HI-6100 Field Monitor HI-6100
30 | Laser-Powered Field Probes: HI-6122 Electric Field Probe
Archived 6/29/10
Use only the content for
HI-4422 in this manual.
Disregard content for
all other probe models;
see ETS-Lindgren
website for other
probe content.
