HI-6113 Laser Data Interface Configuration
The following diagram illustrates the ETS-Lindgren probes that may be used with
the HI-6113 Laser Data Interface (LDI). In the diagram, the USB in HI-6153USB,
for example, refers to USB Kit. As a kit, the probe includes all components
required to operate the probe with the HI-6113.
Typical Configurations
| 19
Archived 6/29/10
Use only the content for
HI-4422 in this manual.
Disregard content for
all other probe models;
see ETS-Lindgren
website for other
probe content.
