117.22 TABLE TOP
121.82 REF
119.12±.25 PIT
OPENING DIMENSION, REF
A A
REFER TO SUB ASSY DRAWINGS FOR PARTS AND BOM'S 1.
SEE P/N 398797 FOR WIRING DIAGRAM 2.
2
10.88 MIN
12.43 MAX
1
.25 GAP BETWEEN TABLE TOP
AND BRUSH HOLDER
.13 FROM TABLE TOP TO
TOP OF BRUSH HOLDER EDGE
SECTION A-A
SCALE 1 : 3
TURNTABLE,3M,MD,ELECTRIC,METAL TOP
1:8
2187-3.0
A
1 1
7/16/07
X.XX
X.XXX .005
.015 .5
NONE
REF DRAWING
ECN REV APPROVED
REVISIONS
DESCRIPTION DATE
DO NOT SCALE DRAWING
ETS LINDGREN
SIZE
THIRD ANGLE PROJECTION
ENGINEERING
INITIAL
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES
REMOVE ALL BURRS AND SHARP EDGES
SURFACE FINISH 63 RMS OR BETTER
FINISH
TOLERANCES ARE:
DECIMALS
±
± ±
ANGLES
DRAFTING
PERMISSION OF ETS LINDGREN
IS PROHIBITED.
ANY DUPLICATION OF THIS
PROPRIETARY INFORMATION
ITEM#
WITHOUT EXPRESS WRITTEN
DOCUMENT, WHOLE OR IN PART,
DATE
TITLE
QTY PART#
OF SHEET
DWG. NO.
An ESCO Technologies Company
DESCRIPTION
SCALE
D
TM
REV.
1 1 111329 TURNTABLE,2187-2.0
1 INITIAL BUILD -
RBG
SUB-ASSY,TOP,TURNTABLE,2187-3.0 112131 1 2
3 1 112132 KIT,SHIPPING,TURNTABLE,2187-3.0
RBG 2/18/08 RELEASED TO STANDARD A 5407
