Ets lindgren – ETS-Lindgren 2187 Turntable User Manual
Page 33
15
6
16
19
7
11
17
9
18
2
13
14
20
24
8
21
32
31
3
4
23 22
5
26 27
34 28 35
36
35
37 35
29
25
37
12
26
27
1 33 35
10 30
REF
ITEM#
QTY
PART#
DESCRIPTION
44
1
398797
WIRING DIAGRAM,2187 ELECTRONIC ASSY (NOT SHOWN)
43
20
890983
SLEEVING,SLIT-CONVOLUTED,PE,1/4" ID (NOT SHOWN)
42
4
708040
FIBER OPTIC CABLE LIMIT SWITCH 1.5M (NOT SHOWN)
41
1
675294
CABLE,ENCODER,8 METER SHIELDED (NOT SHOWN)
40
1
890191
CONN 90DEG CONDUIT FLX (NOT SHOWN)
39
1
920228
LABEL,EQUIPMENT CHECKED (CAL) (NOT SHOWN)
38
25
890192
CONDUIT,FLEX 1/2" RF SHIELDED (NOT SHOWN)
37
4
930997
SCREW,M10X1.5X50,SH,CAP,SS,DIN 912-A2
36
4
930734
SCREW,M8 X 1.25 X 25mm,FLAT,SOCKET,SS
35
.01
920081
LOCTITE THREAD LOCKING #242 31 50MI
34
10
910620
BOLT,5/8-11 X 1-3/4,HEX,GR5,ZN
33
10
910619
SCREW,5/8-11 X 1.25,SH,FLAT,SS
32
32
910616
SCREW LEVELING 1/2-13 X 3 SQ HD CU
31
32
910615
NUT,3/8-16,HEX,ZINC,SERRATED FLANGE
30
4
910603
SCREW,1/4-20 X 7/8,PHIL,FLAT,SS
29
2
910599
BOLT,3/8-16 X 2-1/2,HEX,SS
28
10
910539
WASHER,5/8,LOCK,STL,ZN,SPLIT
27
8
910456
WASHER,1/4,LOCK,SS,SPLIT
26
8
910436
BOLT,1/4-20 X 1/2,HEX,SS
25
2
910411
WASHER,3/8,LOCK,STL,ZN,SPLIT
24
24
910367
NUT,1/2-13,HEX,SERRATED FLANGE,ZN
23
4
910244
SCREW,8-32 X 3/8,PHIL,BIND,SS
22
4
910228
WASHER,#8,LOCK,SS,SPLIT
21
8
890668
CASTER 3A886 GRAINGER
20
24
890238
SCREW LEVELING 1/2-13 X 3 SQ HD CU
19
1
880315
PINION,16T,4DP
18
1
880314
GEARBOX,SEW EURODRIVE
17
1
880216
SHAFT COLLAR,1 1/4 BORE,TWO PIECE,STEEL
16
1
880215
LOCKING COUPLER TLK 200 X 1.25 BROWNING
15
1
880044
BEARING,25.15 OD.,99T
14
1
111332
BASE PLATE,LOWER,2187 TURNTABLE
13
1
111331
BASE PLATE,GEAR BOX,2187 TURNTABLE
12
1
110932
DRIVE,TURNTABLE,2187
11
1
110917
SHAFT,DRIVE,GEARBOX,2187
10
4
110901
STANDOFF,MECHANICAL LIMIT SWITCH ASSY
9
2
110898
BLOCK,GEARBOX TORQUE
8
1
110897
SUPPORT,BEARING/GEARBOX
7
1
110896
SPACER,PINION
6
1
110895
MOUNT PLATE,GEARBOX
5
1
109307
BRACKET,LIMIT SWITCH CASE
4
1
108758
ASSY,MECHANICAL LIMIT SWITCH,MOTORBASE
3
4
106982
FLOOR PLATE SPACER 3, MODEL 2088
2
8
106789
TIE PLATE 2M 2087
1
4
105812
BLOCK 1 BEARING 2087 2M TURNTABLE
TURNTABLE,2187-2.0
1:4
111329
A
1
1
10/27/06
X.XX
X.XXX
.005
.015
.5
NONE
REF DRAWING
ECN
REV
APPROVED
REVISIONS
DESCRIPTION
DATE
DO NOT SCALE DRAWING
ETS LINDGREN
SIZE
THIRD ANGLE PROJECTION
ENGINEERING
INITIAL
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES
REMOVE ALL BURRS AND SHARP EDGES
SURFACE FINISH 63 RMS OR BETTER
FINISH
TOLERANCES ARE:
DECIMALS
±
±
±
ANGLES
DRAFTING
PERMISSION OF ETS LINDGREN
IS PROHIBITED.
ANY DUPLICATION OF THIS
PROPRIETARY INFORMATION
WITHOUT EXPRESS WRITTEN
DOCUMENT, WHOLE OR IN PART,
DATE
TITLE
OF
SHEET
DWG. NO.
An ESCO Technologies Company
SCALE
D
TM
REV.
5190
A
RELEASED
10/27/06
RBG
RBG
