Specifications | 13
3.0 Specifications
Electrical Specifications
Drive Speeds: Variable
Nominal AC Voltage: 208–230 VAC
Input Frequency: 50/60 Hz
Current Rating: 15 amp service
Current Draw: < 10 amps
RPM: 0.5–2.0
Phase: Single (1)
Mechanical Specifications
Diameter: 2.03 meters 3.03 meters
Minimum Height:
27.63 cm
10.88 in 27.63 cm
10.88 in
Maximum Height:
31.57 cm
12.43 in 31.57 cm
12.43 in
Required Pit Diameter:
202.56 cm ± .63 cm
79.75 in ± .25 in 302.56 cm ± .63 cm
119.12 in ± .25 in
Distributed Load Rating
:
910 kg
2000 lb 1100 kg
2500 lb
Distributed Load Rating applies when:
• Load is evenly distributed on top;
• No point loads under 0.19 sq m (2.0 sq ft) should exceed 100 kg
(220 lb);
• And not over 28.5 kg (62.8 lb) should be applied to a 45-degree
segment at the table outer edge.
