6.0 Assembly and Installation
Before assembling, installing, or connecting any components,
follow the safety information in the ETS-Lindgren
Product Information Bulletin included with your shipment.
Prior to assembly and installation, review the drawings located in the back
pocket of this manual.
Proper installation of the turntable directly affects performance. The installation of
turntables two meters and larger will be performed by factory installation
specialists or individuals authorized by ETS-Lindgren to perform such work. The
following installation information is included only to provide an informational
overview of the installation process.
1. Uncrate all parts and check for shipping damage. Create a clear area to
safely assemble the turntable unit. Do not discard any packing material
until unit is fully assembled.
2. Remove the bolts that attach the top onto the turntable drive assembly.
Make note of the placement of each top section as it is removed.
Only qualified personnel should use a forklift or other lifting
machinery to lift the turntable assembly.
3. Using a forklift or other appropriate lifting machinery, place the turntable
bottom or bearing support section into position. If the turntable is to be
installed in a pit, center and level the assembly.
Make sure power is off and secured before proceeding.
4. The drawings in the back of this manual show the placement of floor
plates and leveling screws to anchor and level the turntable. Anchor the
turntable through the attachment holes using the concrete expansion
bolts provided. After installing the floor plates and leveling screws, level
the entire turntable by adjusting all the leveling screws between and
under the casters, and in the center section of the turntable.
5. Tighten all lock nuts accompanying the leveling screws to lock the height
of the turntable into place.
