EFCO CORPORATION 6/2012 PART NO. Y550

6

Series 5500 Outside Glazed Installation Instructions

Install gasket to each end of horizontal before attaching to vertical. Trim excess gasket material after assembly

.

After each frame unit assembly is complete, wipe off all

excess sealant and allow the frame unit to cure.

Apply a generous bead of seal-

ant to the ends of the horizontal

mullion to a minimum of 1” back
from the face of the horizontal

glazing pocket.

INTERMEDIATE HORIZONTAL

Optional Gasket seal
H10Z

OR

Section II: Frame Unit Assembly & Frame Sealing
