EFCO S5500 Outside Glazed User Manual
Page 17
EFCO CORPORATION 6/2012
PART NO. Y550
Series 5500 Outside Glazed Installation Instructions
Section III: Typical Anchorage Methods
NOTE: When welding, protect installed
metal and glass from weld splatter.
NOTE: The elevation of the structure must be within
the adjustment limits of the anchoring system. See
approved shop drawings for limitations.
WELDED DEAD LOAD ANCHORS
STEEL ANCHOR PER
SHOP DRAWINGS
Weld to building structure per
approved shop drawings.
BUILDING
STRUCTURE
