Document #98260100 1 - 3

Step 4

Remove all components except the dyno and

check the contents.

Step 5

Remove bolts holding down the dyno.

Install handle into receivers and secure with 1/4"

bolts. Raise the handle to engage the wheel so the

dyno will roll.

Step 6

To lift the dyno off the crate, use a continuous

loop strap and hook on all four corners of the

main frame (Refer to the picture on the next

page).

Important:

Loop the straps so that they cross at the
top.

Correct

Incorrect
