3 - basic dynamometer operation, Chapter 3, Basic dynamometer operation – Dynojet 224: Pit Eddy Current Brake User Manual
Page 43

Model 224 Pit Eddy Current Brake Installation and User Guide
3-1
C
H A P T E R
3
B
ASIC
D
YNAMOMETER
O
PERATION
The Dynojet dynamometer (dyno) gives state of the art technology, durability, and
accuracy that you need. Dynojet’s advanced engineering delivers the precise
horsepower measurements a technician needs to make quick and accurate
evaluations of engine performance and drive train problems.
This chapter will walk you through loading and preparing your dynamometer and
includes instructions for basic dyno operation. For more detailed instructions, refer
to the WinPEP 7 User Guide. This manual can be found on your WinPEP CD or at
www.dynojet.com/manuals.shtml.
This chapter is divided into the following categories:
• Loading the Car, page 3-2
• Connecting the RPM Pickup, page 3-5
• Pre-Run Inspection, page 3-8
• Making a Run, page 3-10
