58 MIDI Implementation Dave Smith Instruments
1011 nnnn 0100 1010 0vvvvvvv Brightness: When assigned to Pedal 1 or
Pedal 2
1011 nnnn 0000 1101 0vvvvvvv Expression: When assigned to Pedal 1 or
Pedal 2
1011 nnnn 0010 0000 0vvvvvvv Bank Select: 0 - 7
1011 nnnn 0100 0000 0vvvvvvv Damper pedal: Sends 0 if off, 0111 1111
when on
1011 nnnn 0000 0111 0vvvvvvv Volume knob
See sections below for additional Continuous Controller (CC) and Non-registered
Parameter Number (NRPN) messages transmitted.
Additional Continuous Controllers Transmitted/Received
The following table details how MIDI Continuouse Controllers (CCs) are
mapped onto Prophet 12’s controls. They are transmitted when MIDI Param Send
is set to CC in Global, and recognized when received when MIDI Param Receive
is set to CC in the Global menu.
CC# Param
1 Mod Wheel
2 Breath
3 BPM
4 Foot Controller
5 Glide Mode
6 Data Entry MSB
7 Volume
8 Osc 1 Sub Octave
9 Distortion Amount
10 Pan Spread
11 Expression
12 Voice Volume
13 A/B Mode
14 Slider 1 Position
15 Slider 2 Position
16 Slider 1 Pressure
17 Slider 2 Pressure
CC# Param
18 Delay 1 Time
19 Delay 1 Sync
20 Delay 1 Amount
21 Delay 1 Feedback
23 Delay 2 Time
24 Delay 2 Sync
25 Delay 2 Amount
26 Delay 2 Feedback
28 Delay 3 Time
29 Delay 3 Sync
30 Delay 3 Amount
31 Delay 3 Feedback
32 Bank Select
33 Delay 4 Time
34 Delay 4 Sync
35 Delay 4 Amount
36 Delay 4 Feedback
