Modulation
The Prophet 12 has eight fixed-source modulation paths and a 16 x 2 modulation
matrix where the mod sources and destinations are completely user configurable.
There are 27 modulation sources and 98 destinations. For complete lists of all the
sources and destinations, see page 49 and page 50.
To display the mod routings, press either of the a
SSign
m
od
buttons in the Modu-
lation section.
B1 P32: Heavy Dumplings
Mod 3:
Mod 2:
Mod 1: Mod Wheel 23 LFO 1 Amount
Slider 1 Position 50 LPF Cutoff
Slider 2 Position -50 HPF Cutoff
Sort Source Sort Dest
Edit Mod 1
Sort Slot
Source Amount Destination
Soft knob 1 selects the modulation slot to edit.
Source (Soft knob 2) sets the modulation source.
Amount (Soft knob 3) sets the amount of modulation from the source to the desti-
nation. Amount can be set over a range of -127 to 127.
Destination (Soft knob 4) sets the modulation destination.
Sort Slot (Soft key 1) sorts the 24 mod slots in order.
Sort Source (Soft key 2) sorts the mod slots by Source, to more easily see how a
single source may be routed to multiple destinations.
Sort Dest (Soft key 3) sorts the mod slots by Destination, to more easily see how
multiple sources may be routed to a single destination.
