55 Prophet 12 Module Operation Manual MIDI Implementation
MIDI Implementation
Prophet 12 receives MIDI data according to the mode controls under g
loBal
. In
addition, there is interaction between some of the Program parameters that deter-
mine the overall response of Prophet 12 to MIDI data.
Following are the Global parameters that affect response to MIDI:
MIDI Channel: ALL, 1…16 — Selects the MIDI channel to send and receive
data, 1 to 16. All receives on any channel.
MIDI Clock Mode: See table — Selects the MIDI clock status as follows:
Display MIDI Clock Setting
Off MIDI clock is neither sent nor received
Master MIDI clock is sent, but not received
Slave MIDI clock is received, but not sent
Slave Thru MIDI clock is received and passed to MIDI Out
MIDI Clock Cable: MIDI Port, USB— Selects the MIDI port by which MIDI
clock data is transmitted and received.
MIDI Parameter Send: NRPN, CC, Off— Changes to the values of Prophet
12’s front panel controls are transmitted via MIDI as Non-registered Parameter
Number (NRPN) controllers or as Continuous Controllers (CC). Transmission of
parameters can also be turned off.
MIDI Parameter Receive: All, NRPN, CC, Off— Sets the method by which
Prophet 12 receives parameter changes via MIDI. As with transmission, NRPNs
are the preferred method, though some controllers may only be able to send CCs.
MIDI Control Enable: Off, On— When On, the synth will respond to MIDI
control messages, including Pitch Wheel, Mod Wheel, Pedal, Breath, Volume,
and Expression.
MIDI SysEx Enable: Off, On— When On, the synth will respond to received
MIDI SysEx messages, and will transmit them, when prompted, to the MIDI Out.
MIDI Out Select: Off, MIDI, USB, MIDI+USB— Selects the output to use for
MIDI transmissions.
