Dataram DRH380G4 User Manual
Dataram Hardware
CUSTOMER SUPPORT
Dataram's Technical Support Program goes beyond the lifetime warranty,
routine calls and questions. As memory specialists since 1967, we want
to provide the most comprehensive level of service and support in the
industry.
Our Customer Support representatives can answer your questions and
give you information on system/memory configurations, upgrade options,
product specifications, compatibility and other technical topics or issues.
In Europe:
+45 70 212 217 (Phone)
+45 70 212 211 (FAX)
(E-mail)
In the U.S.A. and all other countries:
800-599-0071 (Toll Free)
609-799-0071 (Phone)
609-936-1369 (FAX)
(E-mail)
If a Dataram memory board does not function properly we will issue a
Return Material Authorization number (RMA#) for the return of the
defective module(s) and express ship a repair or replacement to you at
no charge.
P/N 06693 A
P/N 06693 A
DRH380G4 INSTALLATION INSTRUCTIONS FOR
HP PROLIANT DL380 G4 AND ML370 G4 SERVERS
SYSTEM AND MEMORY OVERVIEW
Note: Refer to your system owner’s manual for detailed instructions and be
sure to follow all static and safety precautions.
• The ProLiant DL380 G4 has 6 DIMM slots. Except for a single DIMM
in the first slot, odd numbered DIMMs are not supported—modules
must be installed in matched pairs. If installing both single and dual-
rank DIMMs, the dual-rank DIMMs must be installed in slots 1 and 2.
Dual-rank DIMMs are not supported in slots 5 and 6. The Online
Spare Option is not supported when dual-rank DIMMs are used. No
more than the equivalent of 8 ranks total can be installed.
• The ProLiant ML370 G4 has 8 DIMM slots. Dual-rank DIMMs are not
supported.
Cap Dataram
HP
Description
1GB
DRH380G4/1GB
343055-B21
2x512MB SR DIMMs
2GB
DRH380G4/2GB
343056-B21
2x1GB SR DIMMs
4GB
DRH380G4S/4GB
343057-B21
(SR=Single-Rank; DR=Dual-Rank)
2x2GB SR DIMMs
4GB DRH380G4D/4GB 375004-B21
2x2GB
DR
DIMMs
CUSTOMER SUPPORT
Dataram's Technical Support Program goes beyond the lifetime warranty,
routine calls and questions. As memory specialists since 1967, we want
to provide the most comprehensive level of service and support in the
industry.
Our Customer Support representatives can answer your questions and
give you information on system/memory configurations, upgrade options,
product specifications, compatibility and other technical topics or issues.
In Europe:
+45 70 212 217 (Phone)
+45 70 212 211 (FAX)
(E-mail)
In the U.S.A. and all other countries:
800-599-0071 (Toll Free)
609-799-0071 (Phone)
609-936-1369 (FAX)
(E-mail)
If a Dataram memory board does not function properly we will issue a
Return Material Authorization number (RMA#) for the return of the
defective module(s) and express ship a repair or replacement to you at
no charge.
P/N 06693 A
P/N 06693 A
DRH380G4 INSTALLATION INSTRUCTIONS FOR
HP PROLIANT DL380 G4 AND ML370 G4 SERVERS
SYSTEM AND MEMORY OVERVIEW
Note: Refer to your system owner’s manual for detailed instructions and be
sure to follow all static and safety precautions.
• The ProLiant DL380 G4 has 6 DIMM slots. Except for a single DIMM
in the first slot, odd numbered DIMMs are not supported—modules
must be installed in matched pairs. If installing both single and dual-
rank DIMMs, the dual-rank DIMMs must be installed in slots 1 and 2.
Dual-rank DIMMs are not supported in slots 5 and 6. The Online
Spare Option is not supported when dual-rank DIMMs are used. No
more than the equivalent of 8 ranks total can be installed.
• The ProLiant ML370 G4 has 8 DIMM slots. Dual-rank DIMMs are not
supported.
Cap Dataram
HP
Description
1GB
DRH380G4/1GB
343055-B21
2x512MB SR DIMMs
2GB
(SR=Single-Rank; DR=Dual-Rank)
DRH380G4/2GB
343056-B21
2x1GB SR DIMMs
4GB
DRH380G4S/4GB
343057-B21
2x2GB SR DIMMs
4GB DRH380G4D/4GB 375004-B21
2x2GB
DR
DIMMs
